Mitsubishi DX-TL900U Nine Channel DVR with 120GB Hard Drive

9 Video Input Digital Video Recorder

Embedded DVRs pale in comparison to the operational and networking features, reliability, and upgradeability of a Hartford Digital DVR. However, in the right circumstance, this type of DVR can be ideal. If minimal downtime, access security and feature expandability are not at the top of your DVR shopping list, heres an economic solution for smaller businesses to keep a digital eye on the shop while youre away. This is a great option for replacing a Time Lapse VCR.

The DX-TL900U Nine-Channel Digital Video Recorder offers the winning combination of value, performance and small size.  Advance features include unique recording settings to optimize storage capacity, real time recording speed of 30 pps and built in motion detection.  Plus, our user friendly design makes the transition from analog recording easier and faster than youd ever thought possible.  When it comes to value, the entry level DX-TL900U is the ideal digital video recorder to replace existing analog systems.  For network remote management capability you can connect the DX-VS1UE video server (not included).



  Unique recording settings optimize storage capacity

  Real-time recording (30pps) speed

  Remote monitoring capabilities, including PTZ control, with optional DX-VS1UE

  21 days of 24 hour recording at 1pps per camera

  Built-in motion detection per input


Mitsubishi DX-TL900U Nine Channel DVR
w/120GB $1,099
  w/240GB $1,449

Back to top



Recorder Type

Digital Recorders


1 output, rear panel, 1V p-p, 75 ohms

Video Signal Format


System Resolution

684 x 240

Compression Method


Picture Grades Quality Settings

5 selectable settings (Super, High, Standard, Basic, Long)

System Recording Speed

30 pictures per second record speed

System Recording Intervals

0.125, 0.25, 0.5, 1, 2, 3, 5, 6, 7.5, 10, 15, 30 (pps)

Internal Storage Device

120 GB built in hard disk drive

Removable Storage Device

Compact Flash Cards (CFC) 128 Mb.


FCC Part 15 Subpart B, Class A


UL and cUL 60950

Network Connectivity

Optional via VS1UE Video Server Box

RS-232 Communication

Connector: D-sub 9 pin connector
Transfer speeds: 1200 19.2K bps

Miscellaneous Inputs

Clock / REC / Emergency / Mode Out / Call Out / 5vdc

Video Input/Output

9 looping inputs, 1 v p-p, auto-termination.

Video Input/Output

Composite Video (Rear) output, BNC, 1V p-p, 75 ohms
Composite Video (Front) 1 Output, RCA (f), 1V p-p, 75 ohms

Audio Input

Input: Single input, rear panel

Audio Output

2 outputs, front and rear panels, RCA (f)

Operating Temperature

41F - 104F (5C - 40C)

RS-232C Interface

Connector: D-sub 9 pin connector
Transfer speeds: 1200 19.2K bps

Input Voltage

100 - 240 VAC 50/60HZ

Power Consumption

Approx. 18 watts


3.5 x 11.8 x 13.8 in. (88 x 300 x 350 mm)


15.4 lbs. (7.0 kg)


Max. 80%

ALM Input

9 alarm inputs, activated by alarm closure (n/o)


*Optional DX-VS1UE connects to the RS-232 Connection
